1.47 Inch Tft bar Lcd SPI Display with 172×320 for Smart Home Appliances Lcd Module
القسم: غير مصنف
24 ر.ق
حالة التوفر: متوفر في المخزون
10000 متبقي
قسط على
4
دفعات
ر.ق6.00
مع خدمة
باي ليتر شحن دولي
يرجى معاينة تفاصيل المنتج لمعرفة بلد المنشأ والشحن
مشاركة المنتج
- Brand Name: NONE
- Origin: Mainland China
- Display Mode: TFT LCD
- High-concerned chemical: None
- Resolution: 172×320
- Model Number: ORC-T014703N-V06
- Type: TFT
Product Paramenters
Product Name | 1.47 Inch Round TFT LCM Display | |
Model No. | ORC-T014703N-V06 | |
Parameter | Value | Unit |
Display size | 1.47 | inch |
LCD Mode | TFT | – |
Display Color | 262K | – |
Pixel Pitch | 0.114(H)x0.115(v) | um |
Display Resolution | 172(RGB)*320 | Pixels |
Module Size | 19.65(H)*36.76(W)*1.56(T)(EXCLUDE FPC) | mm |
Active Area(A.A) | 17.65(H)*32.83(W) | mm |
Display Mode | Normally Black | – |
Viewing Direction | all | – |
Driver IC | ST7789P3 | – |
Interface | SPI | – |
Back-light LED | 2 Parallel 1serial | – |
OEM & ODM accepted | Focused on TFT-LCD & AM-OLED Display over 15 years. | |
Product Detail
Company Profile
