AGS10 MEMS TVOC Gas Sensor – ±5% Accuracy 0-30ppm, I2C Output, Smart Home Air Quality Monitor, Replace AGS02MA for Air Purifier
القسم: غير مصنف
20 ر.ق
حالة التوفر: متوفر في المخزون
999 متبقي
شحن دولي
يرجى معاينة تفاصيل المنتج لمعرفة بلد المنشأ والشحن
مشاركة المنتج
- Brand Name: NONE
- Origin: Mainland China
- Condition: New
- High-concerned chemical: None
AGS10 is a MEMS TVOC sensor with digital I2C signal output. Equipped with special digital module acquisition technology and gas.
Inductive sensing technology ensures that the product has high reliability and excellent long-term stability, as well as low power consumption, high sensitivity and high speed.
Fast response, low cost and simple driving circuit.
Arduino library can directly manage and search AGS02 after version 1.8.
trait
Working voltage: 3.0-6.0v.
Typical power: 75mW
Sampling period: ≥2s
Interface rate: I2C slave mode (≤15kHz)
Preheating time: ≥120s
Working temperature: 0 ~ 50℃
Working humidity: 0 ~ 95% RH
Life: > 5 years (25℃, in clean air)
Output unit: ppb
Measuring range: 0 ~ 99999 ppb
Typical accuracy (25℃/50%RH): 25% reading.
Standard test gas: ethanol
Module size: 15*10.6mm
Inductive sensing technology ensures that the product has high reliability and excellent long-term stability, as well as low power consumption, high sensitivity and high speed.
Fast response, low cost and simple driving circuit.
Arduino library can directly manage and search AGS02 after version 1.8.
trait
Working voltage: 3.0-6.0v.
Typical power: 75mW
Sampling period: ≥2s
Interface rate: I2C slave mode (≤15kHz)
Preheating time: ≥120s
Working temperature: 0 ~ 50℃
Working humidity: 0 ~ 95% RH
Life: > 5 years (25℃, in clean air)
Output unit: ppb
Measuring range: 0 ~ 99999 ppb
Typical accuracy (25℃/50%RH): 25% reading.
Standard test gas: ethanol
Module size: 15*10.6mm
